NUCLEUS ELECTRONIC TECHNOLOGY

USA Mexico and EU countries tax free 1350watt 4 channel audio power pa amplifier for party

USA Mexico and EU countries tax free 1350watt 4 channel audio power pa amplifier for party

$1,566.72 USD
$0.00 USD $1,566.72 USD
Sale Sold out
Color
DS-10Q AMPLIFIER SPECIFICATIONS
DS-10Q AMPLIFIER SPECIFICATIONS
DS-10Q
8Ω Stereo Power
1350W  * 4CH
4Ω Stereo Power
2100W * 4CH
8Ω Bridged Power
4200W * 2CH
4Ω Bridged Power
5000W * 2CH
Frequency Response(+o/-0.3dB,1W/8Ω)
20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W
<0.1%
Signal-to-Noise Ratio
>112 dBA
Channel separation (Crosstalk) at 1 kHz
>70 dB
Input Connectors (per channel)
3-pin XLR, electronically balanced
Output Connectors (per channel)
Binding Posts 2-pole
Class
TD
RK Dual 8" line Array System 16+8 Hanging Combination Set wit.TourClass Protection
ACL,IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input
Operating voltage
220 V / 110 V nominal ； 180-240 V / 90-130 V selectable
Voltage Gain(dB)
23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance
20 kOhm
Level adjustment (per ch.)
Front-panel potentiometer, 31 position detented from -inf to 0 dB

DS-10Q FEATURE:
-Good for dual 15 inch Speaker ,double 10/12 inch line array.
-Create SUPER sound quality.
-Separately controllable on Gain.
-Scalable Voltage Peak Limiter (VPL).
-Bridge-mode operation for Touring Applications.
-Comprehensive protection scheme.
-Use Original capacitor 3300uf 200V.
-Use Original power output transistor and XLR.

Unique cooling system:

We upgrade cooling system, add rear fans ,which is Enhance cooling system capability of the amplifier. Quiet and efficient, fast heat dissipation.

Capacitor Upgrade:

The old version we use 10 pcs 3300UF/200V capacitor +4 pcs 2200uf/200V capacitors, and now the new version is add more 2 pcs 3300uf/200V. Totally add more 6600UF capacitance. The amplifier power supply board is better than before, it will make sound quality more loud and powerful.
Product Description
4 Output Channels Power amplifier
DS-6Q
DS-8Q
DS-10Q
DS-20Q
DS-22Q
8Ω Stereo Power
625W X4
1000W X4
1350W X4
2200W X4
2500W X4
4Ω Stereo Power
1300W X4
1600W X4
2100w X4
4000W X4
4650W X4
8Ω Bridged Power
2500W X2
3200w X2
4200w X2
8000w X2
9000w X2
4Ω Bridged Power
3000W X2
3800w X2
5000w X2
9000w X2
15000w X2
2 Output Channels Power amplifier
DS-14K
DS-9K
DS-7K
DS-24K
If you are interested in more products details , View our Products list or Contact us >>>
8Ω Stereo Power
2400W X2
1800W X2
1500W X2
4200W X 2
4Ω Stereo Power
4400W X2
3000W X2
2800W X2
7500W X 2
8Ω Bridged Power
8800W
6000W
5600W
/
4Ω Bridged Power
14000W
9000W
7000W
/


♦Impedance Matching : Our DS-Series amplifier suitable for impedance above 4ohms and above.

♦How to match our amplifier with your speaker ?
Under certain impedance conditions, our DS-10Q suitable for the speaker rated power around 800W@8ohm(Below 800W also ok ).
♦Suggest match: DS-10Q match with 4pcs Single 15inch or 4pcs Double 15inch professional PA speaker .
♦Best match : DS-10Q match with 2pcs single 15inch full frequency professional PA speaker + 2pcs single 18inch sub woofer .

♦Can I use your DS-10Q to push 400W speaker(8ohms) ?
Yes, you can. Generally , you can choose our amplifier’s power twice of your speaker ’s power, it’s no problem. There is a limiter protection design in our circuit.

♦Does your unit with warranty ?
If there is a problem with your amplifier, please send us pictures or videos, and the engineer will determine the problem and send replacement parts. For specific warranty terms, please click here to view.
